BRIGGS & STRATTON VANGUARD 18HP 570CC VERTICAL ENGINE

Model: 356777-0115-E1

Product Description

The Briggs & Stratton Vanguard 356777-0115-E1 is an 18 gross HP, 570cc vertical-shaft engine designed for outdoor power equipment applications. It features a two-cylinder V-Twin configuration, air-cooled OHV design and a 1-inch vertical crankshaft. Briggs & Stratton identifies the 356700 series as an 18 gross HP, 570cc Vanguard engine family.

This engine uses a float-feed carburetor with an integral fuel pump, Magnetron electronic ignition, Dual-Clean air filtration and full-pressure lubrication with a spin-on oil filter. The documented 356777 configuration includes a 12-volt gear-drive electric starter and 16-amp DC alternator.

Key Features

• Briggs & Stratton Vanguard engine
• Exact model: 356777-0115-E1
• 18 gross HP at 3,600 RPM
• 570cc displacement
• V-Twin, two-cylinder configuration
• Vertical-shaft design
• Air-cooled OHV design
• Durable cast-iron cylinder sleeves
• Float-feed carburetor with integral fuel pump
• Magnetron electronic ignition
• Dual-Clean air filtration with paper filter and foam pre-cleaner
• Full-pressure lubrication system
• Spin-on oil filter
• 12-volt gear-drive electric starter
• 16-amp DC alternator
• 1" diameter x approximately 3-5/32" vertical crankshaft
• 1/4" keyway and 7/16-20 tapped crankshaft end
